GIGABYTE H410M H V2 10th Gen Micro ATX Motherboard
Original price was: 9,500.00৳ .8,400.00৳ Current price is: 8,400.00৳ .
Model: H410M H V2
Supported CPU: 10th Gen Intel Core Processors
Supported RAM: DDR4, 2 DIMMs, up to 64 GB
Graphics Output: 1 x D-Sub, 1 x HDMI
Features: Intel GbE LAN with cFosSpeed
- For wholesale orders, please call to +8801711305668
Overview
GIGABYTE H410M H V2 10th Gen Micro ATX Motherboard
The GIGABYTE H410M H V2 is a high-performance Micro ATX motherboard designed to support 10th Generation Intel Core processors, delivering efficient and reliable computing for both home and office use. With its Intel H470 Express chipset, this motherboard ensures smooth system performance and compatibility with a wide range of CPUs, from Intel Core i9 to Pentium and Celeron processors.
Powerful Performance & Memory Support
Equipped with dual DDR4 DIMM slots, it supports up to 64GB of RAM, ensuring smooth multitasking and enhanced system responsiveness. It also features Extreme Memory Profile (XMP) support for memory overclocking, optimizing performance for demanding applications.
Graphics & Display
The motherboard features an integrated Intel HD Graphics processor, supporting HDMI (4096×2160@30Hz) and D-Sub (1920×1200@60Hz) outputs, making it an excellent choice for high-resolution displays and multimedia tasks.
Storage & Expansion
With one M.2 slot (supporting PCIe x4/x2 SSDs) and four SATA 6Gb/s ports, this motherboard provides ample storage flexibility. It is also Intel Optane Memory Ready, allowing for faster data access speeds.
Connectivity & I/O Ports
The Intel GbE LAN chip ensures stable and high-speed network connectivity. The board includes USB 3.2 Gen 1 and USB 2.0 ports for fast data transfer, along with multiple PCIe slots for expansion, supporting PCIe 3.0 standard for graphics and add-on cards.
Enhanced Reliability & Durability
Designed for long-term use, the GIGABYTE H410M H V2 features a trusted platform module (TPM) header, RAID support, and ASPM L1.2 power management protocols. The Realtek Audio CODEC delivers 7.1-channel high-definition audio, ensuring immersive sound quality for both work and entertainment.
Warranty & Support
Backed by a 3-year warranty, this motherboard offers peace of mind, ensuring reliability and durability for years to come.
Whether you’re building a budget-friendly gaming rig, an efficient workstation, or a home PC, the GIGABYTE H410M H V2 delivers excellent performance, expandability, and stability in a compact Micro ATX form factor.
Details
| specifications |
|---|
| Supported CPU | Support for 10th Generation Intel Core i9 processors/ Intel Core i7 processors/ Intel Core i5 processors/Intel Core i3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1200 package |
|---|---|
| Chipset | Intel H470 Express Chipset |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX Form Factor: 22.6cm x 18.5cm |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
| PCI | 1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slots (The PCI Express slots conform to PCI Express 3.0 standard.) Supports up to ASPM L1.2 power management protocols. |
| Type | DDR4 |
| Slots | 2 x DIMM |
| Supported Memory | Intel Core i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz memory modules Intel Core i5/i3/Pentium/Celeron processors: Support for DDR4 2666/2400/2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Maximum Memory | 64GB (32 GB single DIMM capacity) |
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz 1 x HDMI ports, supporting a maximum resolution of 4096×2160@30 Hz * Support for HDMI 1.4 version and HDCP 2.3. |
| HDMI | 1 x HDMI port |
| D-Sub (s) | 1 x D-Sub port |
| USB (s) | Chipset: 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
| LAN Port (s) | Intel GbE LAN chip (1 Gbit/100 Mbit) |
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) 4 x SATA 6Gb/s connectors Intel Optane Memory Ready M.2 connectors support up to ASPM L1.2 PCIe power management protocols. |
| RAID | Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper |
| TPM (Trusted Platform Module) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| Warranty | 3 Years |
